Mori Seiki NVD5000 α1B/40 CNC Vertical Machining Center – 20000 RPM Mill

Travels:
X-Axis: 1021 mm
Y-Axis: 511 mm
Z-Axis: 511 mm
Spindle Nose to Table (Min.- Max.): 150 mm – 660 mm
Table:
Length: 1321 mm
Width: 599 mm
Max Weight on Table: 1197 kg
Number of T-slots & Size: 6 × 18 mm × 99 mm
Spindle:
Taper Size: BT-40
Speed Range: 20,000 RPM
Spindle Power: 19 kW
Feed Rate:
Rapid X, Y & Z: 19990 mm/PM
Cutting Feed rate: 19990 mm/PM
